DI.PO. s.r.l. is a specialized service centre, leader in stainless steel discs supply.

AISI data sheet 430

Stainless steels containing a good amount of chromium but without addition of nickel and other elements capable of forming austenite.

i ASK US »
* The values shown in the tables are approximate and not binding.
acciai ferritic GO TO THE PRODUCTS SECTION
o learn about thicknesses and available sizes

ALTERNATIVE NAMES

ASTM EN UNS JIS
430 1.4016 S43000 SUS 430

CHEMICAL COMPOSITION

430 Chemical Composition - Maximum Value
C Mn Si Cr Ni P S Other
0.08 1.5 1.0 16-18 0 0.04 0.15-0.35
Typical Value
0.05 1 1.0 16.5 0 0.02 0.15

MECHANICAL CHARACTERISTICS

Tensile Strength (MPa) min Yield Strength 0.2% Proof (MPa) min Elongation (% in 50mm) min Hardness
Rockwell B (HR B) max Brinell (HB) max
450
(480)		 280
(330)		 24 85 201

END USES

AISI 430 is currently the most used ferritic stainless steel grade in the world. The steel is ferromagnetic at ambient temperature and cannot be tempered. This steel contains an average content of Chromium and as such presents average resistance to corrosion.

The grade is used in a vast range of applications, especially for indoors. The presence of small amounts of sulphur can help the workability of this type of steel in mechanical machining for chip removal. Welding ability is reduced, because the material crystalline grain expands at high temperature in the welding points.

Some possible uses are: equipment for bars-restaurants, parts for the food industry, architectural decorative elements, parts for household appliances, vehicle accessories, parts for burners.
